Vertical Lift System with Ring Chain for Heavy Duty Particle Handling Applications

Customization:	Available
Type:	Bucket Conveyor
Structure:	Conveyor System

i

Basic Specifications

Model NO.

Bucket Elevator

Material

Carbon Steel

Material Feature

Fire Resistant

Certification

ISO9001:2008, CE

Warranty

1 Year

Power

4kw - 22kw

Load Capacity

3--60 M3/H

Application

Ore, Coal, Construction

O

Product Overview

Bucket elevator in cement plant, also called cement bucket elevator, is mechanical conveying equipment, mainly apply for the vertical lift of powder, particles like limestone, coal, gypsum, clinker, clay, raw meal, cement, pulverized coal, etc. In general, cement bucket elevator works with cement crushers, raw mills, and other processing equipment.

Full Process Solution Provider:
• Lifting Height: 28-80 m
• Conveying Capacity: 3-650 m³/h
• Material: coal, cement, stone, sand, clay, ore, etc.

T

Technical Specification

Size	Max Lift Height (m)	Capacity (m³/h)	Max Material Size (mm) / Proportion (%)					Motor Power (kw)
Size	Max Lift Height (m)	Capacity (m³/h)	10mm	25mm	50mm	75mm	100mm	Motor Power (kw)
NE15	40	16	65	50	40	30	25	1.5-4
NE30	59	31	90	75	58	47	40	2.2-7.5
NE50	62	60	90	75	58	47	40	3-15
NE100	58	110	130	105	80	65	55	7.5-30
NE150	65	170	130	105	80	65	55	11-37
NE300	61	320	170	135	100	85	70	22-75
NE500	58	500	240	190	145	120	100	45-132

S

Structure & Components

Head Part Assembly

The head part of the bucket elevator is assembled by the upper casing, the main shaft part, the reducer, the coupling, the motor and associated drive components. It is designed for heavy-duty operation and longevity in harsh industrial environments.
