Industrial-Grade Pallet Lifter Systems with Vertical Conveyor Transport for Multi-Level ASRS Facilities
Pallet lift is a logistics solution employed in multiple sectors to raise a load to the desired height. In its simplest form, a pallet lift is a tool widely used in warehouses to elevate goods a number of feet (higher than the reach of a pallet truck but lower than that of a forklift). This can be done to facilitate the loading/unloading of trucks or to improve an operator's access to the products on a pallet.
Vertical conveyors are a more sophisticated version of the pallet lift and are used in Automated Storage and Retrieval Systems. Driven by an electric motor - just like a goods lift ― vertical conveyors are present in warehouses with conveyor systems, such as automated storage and retrieval systems. In this case, they can serve to connect different conveyor line levels, raise a pallet for another machine to pick it up and deposit it on a rack, automate truck loading and unloading, etc.
Advantages of Pallet Elevators
✓
High-bay capability: This multi-level solution lifts pallets up to 40 m in height.
✓
High load capacity: Thanks to their robust construction, vertical lift conveyors can transport pallets weighing up to 3,000 kg.
✓
Great speed: Pallet elevators expedite the vertical transport of palletised loads, achieving speeds of 80 m/min.
✓
Easy integration: Compact single-mast structure adaptable to different layouts and warehouse configurations.
✓
Safe operation: Stable lifting mechanisms safeguard the integrity of the goods transported.
✓
Wide temperature range: Operational in environments from -30 °C to 40 °C.
Technical Specifications
| Item |
Basic Data |
| Motor Reducer |
Lenze Smart Motor |
| Control Mode |
Manual / Automatic / On-line |
| Speed Adjusting Mode |
Frequency Control |
| Safety Method |
Electrical interlocking; Protecting and guiding direction at both sides |
| Pallet Detection |
Photosensor |
| Chain Rail |
Low friction nylon rail |
| Bearing |
Sealed ball bearing |
| Conveyor Speed |
60m/min |
| Surface and Coating |
Aluminum beam with stainless steel chain; Stainless roller, carbon steel leg |
| Noise Level |
≤ 65 dB |
Application Scenarios
Our pallet conveyors offer seamless interfacing with a variety of host systems to enable operational data, diagnostic reports, and dynamic responses to changes in product flow. Patented bolted construction and modular designs ensure robust, easy installations that integrate with existing equipment.
Receiving: Move incoming pallets to the right place for unloading or storage.
Palletizing: Transport empty and full pallets into position for handling.
Load storage: Ensure efficient, stable pallet flow into and out of storage.
Outbound Staging: Accumulate pallets in proper sequence for shipments.
AS/RS Integration: Direct stable flow to and from dense automated storage.
Manufacturing: Ensure smooth flow for end-of-line stacking and labeling.
System Capabilities
Our Workflow
Step 1 Define: Engineers work with stakeholders to determine project objectives.
Step 2 Measure: Information is collected to understand business requirements.
Step 3 Analyze: Operating system data is used to create predictive models.
Step 4 Design: Best-fit layouts and technical configurations are developed.
Step 5 Validate: System costs are estimated and feasibility analysis is completed.
Step 6 Presentation: Clients receive a final presentation of costs and the optimal solution.
Frequently Asked Questions
Q: What types of automated storage systems do you provide?
We provide Unitload AS/RS (pallet type), Miniload AS/RS (box/container type), shuttle sequencing systems, and rack-supported building AS/RS solutions.
Q: What is the maximum load and height for the vertical pallet lifters?
The system can handle pallet loads up to 3,000 kg and can reach heights of up to 40 meters, making it suitable for high-bay warehouses.
Q: Can the conveyor systems operate in cold storage environments?
Yes, our vertical conveyor systems are designed to operate in a wide temperature range, from as low as -30 °C up to 40 °C.
Q: What are the typical speeds of these pallet elevators?
The systems can achieve vertical speeds of 80 m/min for 1,000 kg payloads and 60 m/min for payloads up to 1,500 kg.
Q: How do you ensure the safety of the goods and operators?
We use electrical interlocking, photosensors for pallet detection, and side-guiding directions to ensure stable and safe movement at all times.
Q: Do you offer turnkey project management?
Yes, we provide end-to-end services including consulting, design, manufacturing, implementation, training, and after-sales commissioning.
